Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 500mV
Data Rate 1Mbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 1098729-SN65C3221EDBR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65C3221EDBR CAD Model

Description

The SN65C3221EDBR is a robust, high-performance RS-232 transceiver from Texas Instruments, designed to meet the needs of demanding serial communication applications. This integrated circuit is part of the SN65C3221 series and comes in a compact SSOP (Shrink Small Outline Package) form factor, making it an ideal choice for space-constrained environments.

Key Features

  • Interface Type: The device supports RS-232 standards, ensuring compatibility with serial communication protocols widely used in computer and networking equipment.
  • Number of Drivers/Receivers: It features one driver and one receiver, providing a full-duplex communication capability.
  • Data Rate: The SN65C3221EDBR offers a data transfer rate of up to 1Mbps, making it suitable for high-speed data exchange.
  • Supply Voltage: It operates on a 3V to 5.5V supply voltage, giving designers flexibility in various power supply scenarios.
  • Electrostatic Discharge (ESD) Protection: The device includes integrated ESD protection circuitry, safeguarding against electrostatic discharges up to ±15kV, thereby enhancing system reliability.
  • Low Power Consumption: Designed for efficiency, it features a low-power shutdown mode that significantly reduces power consumption when not in active use.

Applications

The SN65C3221EDBR is well-suited for a range of applications that require reliable serial communication. Its typical applications include:

  • Industrial control systems
  • Point-of-sale (POS) terminals
  • Data acquisition systems
  • Networking equipment such as routers and switches
  • Medical equipment with serial interfaces

Package and Quality

The device is offered in a 16-pin SSOP package, which is known for its small footprint. Texas Instruments is committed to high-quality manufacturing standards, and the SN65C3221EDBR is no exception. It is designed to meet or exceed the stringent requirements of industrial and commercial applications, ensuring reliability and performance.

Conclusion

In essence, the SN65C3221EDBR from Texas Instruments is a versatile and reliable RS-232 transceiver that is well-suited for a variety of applications where efficient and secure data communication is essential. Its combination of high-speed data rates, low power consumption, and robust ESD protection makes it a preferred choice for designers and engineers looking for a dependable serial communication solution.
