Products specifications Report Issue?

Category Integrated Circuits (ICs)>Interface - Analog Switches, Multiplexers, Demultiplexers
Mfr Analog Devices Inc./Maxim Integrated
Package Tube
Switch Circuit SP4T
Number of Circuits 2
On-State Resistance (Max) 1.5Ohm
Voltage - Supply, Single (V+) 3V ~ 5.5V
Switch Time (Ton, Toff) (Max) 2ms, 1.5ms
-3db Bandwidth 75MHz
Charge Injection 1720pC
Channel Capacitance (CS(off), CD(off)) 78pF
Current - Leakage (IS(off)) (Max) 1µA
Crosstalk -103dB @ 100kHz
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 20-WQFN Exposed Pad
Supplier Device Package 20-TQFN (5x5)
Base Product Number MAX14778
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Standard Package 60
Win Source Part Number 1130223-MAX14778ETP+
Ultra Librarian 3D Model Ultra Librarian MAX14778ETP+ CAD Model

Description

Maxim Integrated MAX14778ETP+ Overview

The Maxim Integrated MAX14778ETP+ is a versatile, high-performance analog multiplexer/demultiplexer (mux/demux) that provides precision signal routing for analog and digital signals. This device is an ideal solution for applications that require the routing of multiple signal types through a single connector, such as industrial automation, test equipment, and communication systems.

Key Features

  • Wide Voltage Range: The MAX14778ETP+ operates over a wide single supply voltage range of 4.5V to 36V or a dual supply range of ±4.5V to ±20V, making it suitable for a variety of systems.
  • Low On-Resistance: With a low on-resistance of 175Ω (max), this mux/demux ensures minimal signal attenuation, providing high signal integrity.
  • Multiple Configurations: The device can be configured as a dual 4:1, a single 8:1, or a dual 2:1/4:1 multiplexer, offering flexibility in signal routing.
  • Bidirectional Operation: It supports bidirectional signal flow, allowing it to be used for both multiplexing and demultiplexing applications.
  • ESD Protection: Integrated electrostatic discharge (ESD) protection shields the device from static damage, enhancing its durability and reliability.
  • Break-Before-Make Switching: This feature prevents signal shorting by ensuring that the connection to one channel is broken before making a connection to another.

Applications

The MAX14778ETP+ is designed to serve a broad range of applications, including:

  • Signal Routing in Automated Test Equipment (ATE)
  • Industrial Control Systems
  • Data Acquisition Systems
  • Audio/Video Signal Routing
  • Communication Devices

Package and Reliability

The device is housed in a compact 20-pin TQFN package with an exposed pad for enhanced thermal performance. Maxim Integrated ensures high reliability and performance, making the MAX14778ETP+ a trusted choice for critical signal routing applications.

With its robust feature set and flexible design, the MAX14778ETP+ from Maxim Integrated stands out as an efficient solution for designers looking to streamline their signal routing with precision and ease.
