Products specifications Report Issue?

Category Integrated Circuits (ICs)>Interface - Analog Switches, Multiplexers, Demultiplexers
Mfr Analog Devices Inc./Maxim Integrated
Series *
Package Strip
Product Status Obsolete
Base Product Number MAX14550
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 2156-MAX14550AEETB+-MA,MAXMAXMAX14550AEETB+
Standard Package 1
Win Source Part Number 1074889-MAX14550AEETB+
Ultra Librarian 3D Model Ultra Librarian MAX14550AEETB+ CAD Model

Description

MAX14550AEETB+ - Maxim Integrated

The MAX14550AEETB+ is a highly integrated accessory detection and control IC designed by Maxim Integrated to enhance the capabilities and performance of portable devices. This advanced chip facilitates seamless connectivity between mobile devices and various accessories, ensuring a smooth user experience.

Key Features

  • Accessory Detection: The IC is capable of detecting various accessories, including standard headsets, headsets with microphones, and dedicated charging ports.
  • Audio Switching: It incorporates audio switching capabilities to route audio signals to the appropriate paths when different accessories are connected.
  • Charging Control: The MAX14550AEETB+ supports USB Battery Charging Specification 1.2, enabling optimized charging for connected devices.
  • USB Data Switching: It allows for USB 2.0 full-speed data switching, providing flexibility for peripheral connections.
  • Low Power Consumption: Designed with power efficiency in mind, the device operates with low quiescent current, making it ideal for battery-powered applications.
  • Compact Form Factor: The IC comes in a small, 25-bump wafer-level package (WLP), which is suitable for space-constrained applications.

Applications

The MAX14550AEETB+ is suitable for a wide range of portable electronic devices, including:

  • Smartphones
  • Tablets
  • Portable media players
  • Handheld gaming consoles
  • Other USB-enabled devices requiring accessory detection and control

Technical Specifications

The device operates over a temperature range of -40°C to +85°C, ensuring reliability across various environments. It also features built-in ESD protection, safeguarding the IC against electrostatic discharges that can occur during handling or connection of accessories.

In conclusion, the MAX14550AEETB+ from Maxim Integrated is a versatile and efficient solution for accessory detection and control in portable devices. Its integration of multiple functions into a single chip makes it a valuable component for manufacturers looking to streamline their designs and enhance user experience.
