Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Linear Technology
Packaging Tray
Function Direct Conversion Subsystem
Frequency 700MHz ~ 2.7GHz
RF Type General
Secondary Attributes 9.42MHz Low Pass Filter
Package 204-BLGA
Manufacturer Package 204-LGA (22x15)
Win Source Part Number 784665-LTM9004CV-AC#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTM9004
Introduction Date December 02, 2009
ECCN 5A991.b
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTM9004CV-AC#PBF CAD Model

Description

Product Overview: LTM9004CV-AC#PBF

The LTM9004CV-AC#PBF is a high-performance, μModule® (micromodule) receiver from Linear Technology designed to cater to the demanding needs of communication infrastructure, medical applications, and industrial control systems. This meticulously integrated solution is part of the LTM9000 series, which combines a high-speed 14-bit analog-to-digital converter (ADC) with a fixed gain differential amplifier and an anti-aliasing filter in a compact, shielded package.

Key Features

  • Integrated ADC: The core of the LTM9004CV-AC#PBF is its 14-bit, 125Msps ADC, which offers excellent linearity and noise performance, making it ideal for processing complex signals with high fidelity.
  • Fixed Gain Amplifier: The onboard differential amplifier with a fixed gain ensures that signals are accurately amplified with minimal distortion, facilitating a clean and reliable input for the ADC.
  • Anti-Aliasing Filter: A built-in 4th order Butterworth low-pass filter effectively eliminates unwanted high-frequency noise, preventing aliasing and preserving the integrity of the sampled signal.
  • Compact Design: The LTM9004CV-AC#PBF is housed in a space-saving 15mm x 15mm LGA package, which includes a shielded enclosure to minimize electromagnetic interference (EMI) and enhance signal integrity.
  • Easy Integration: Designed for ease of use, this μModule receiver can be integrated into a system with minimal external components, simplifying the design process and accelerating time-to-market.

Applications

The LTM9004CV-AC#PBF is versatile and can be used in a variety of applications that require high-speed and precise data acquisition, such as:

  • Wireless and Wired Broadband Communication
  • Medical Imaging Systems
  • Radar and Satellite Communication Systems
  • Industrial Instrumentation
  • Data Acquisition Systems

Quality and Reliability

Linear Technology ensures that the LTM9004CV-AC#PBF meets the highest standards of quality and reliability. Each μModule receiver is rigorously tested and guaranteed to perform over its specified temperature range, making it a trusted choice for critical applications where performance cannot be compromised.
