Product Overview: DC1213A from Linear Technology

The DC1213A is a high-performance demonstration board from the reputable Linear Technology, an Analog Devices company. This product is designed to showcase the capabilities of the LTC®3880, a dual, polyphase synchronous step-down DC/DC controller with I²C-based PMBus capability for real-time monitoring and control.

Key Features

• Integrated Design: The DC1213A features a complete design with onboard power components, including MOSFETs and inductors, providing a compact and efficient power solution.
• High Efficiency: The LTC3880 controller enables the DC1213A to operate with high efficiency, making it suitable for a wide range of applications, including telecom, datacom, and storage systems.
• Digital Interface: The I²C/PMBus interface allows for extensive programmability and real-time monitoring of voltage, current, temperature, and fault status, ensuring optimal performance and reliability.
• Versatile Voltage Range: The board supports an input voltage range of 4.5V to 24V, and the output voltage can be set from 0.5V to 5.5V, accommodating various power requirements.
• Polyphase Capability: The DC1213A can be configured for polyphase operation, which reduces input and output ripple and improves thermal performance, making it ideal for high-current applications.

Applications

• Telecommunications Infrastructure
• Data Communication Systems
• Enterprise Computing
• Industrial Systems

Support and Resources

Linear Technology provides comprehensive support for the DC1213A, including detailed datasheets, user guides, and application notes. Technical support is also available to assist with design-in efforts and to help troubleshoot any issues that may arise during the use of this demonstration board.

For engineers and designers looking for a robust and versatile power solution, the DC1213A demonstration board from Linear Technology represents a state-of-the-art option, combining cutting-edge digital power technology with the reliability and performance expected from a leader in power management solutions.
