Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Connectors, Interconnects - Terminals - Spade Connectors
Mfr Keystone Electronics
Package Bulk
Product Status Active
Terminal Type Standard
Stud/Tab Size 8 Stud
Width - Outer Edges 0.320" (8.13mm)
Length - Overall 0.840" (21.34mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 10-12 AWG
Insulation Insulated
Color Yellow
Contact Finish Tin
Contact Material Copper, ETP
Insulation Diameter 0.255" (6.48mm)
Material - Insulation Vinyl
Length - Ring Center to Termination 0.290" (7.37mm)
Length - Termination 0.550" (13.97mm)
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 551206-8234
Ultra Librarian 3D Model Ultra Librarian 8234 CAD Model

Description

The 551206-8234 is a yellow spade connector designed for use in various electrical applications.

  • Termination: Crimp
  • Contact Material: Copper and ETP
  • Insulation: Vinyl
  • Wire Gauge: 10-12 AWG
  • Length: 0.840 inches (21.34mm)
  • Width: 0.320 inches (8.13mm)
  • Terminal Type: Standard
  • Mounting: Free-hanging (in-line)
  • Packaging: Bulk
  • Pieces per Package: 100
  • Product Status: Active
  • Manufacturer: Keystone Electronics
