Same model may have multiple batches, images only for reference.
SU9HD-40008 Real Image
Same model may have multiple batches, images only for reference.

SU9HD-40008

Part No SU9HD-40008
Manufacturer Kemet
Catalog Common Mode Chokes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SU
Package Tray
Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 7.98 µH @ 1 kHz
Current Rating (Max) 4A
DC Resistance (DCR) (Max) 31.25mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 120°C
Mounting Type Through Hole
Dimension 0.669" L x 0.610" W (17.00mm x 15.50mm)
Height (Max) 0.492" (12.50mm)
Package / Case Vertical, 4 PC Pin
Base Product Number SU9HD
Other Names 399-SU9HD-40008,UALSU9HD400080
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 1276456-SU9HD-40008
Ultra Librarian 3D Model Ultra Librarian SU9HD-40008 CAD Model

Description

The KEMET SU Series Common Mode Choke is a power line filter designed to be used in electronic devices and equipment.

  • Manufacturer: KEMET
  • Filter Type: Power Line
  • Voltage Rating: 250V AC
  • Maximum Current Rating: 4A
  • Package: Tray
  • Mounting Type: Vertical, 4 PC pin
  • Number of Lines: 2 lines
  • Inductance @ Frequency: 7.98 µH @ 1 kHz
  • DC Resistance (DCR) (Max): 31.25mOhm
  • Operating Temperature Range: -25°C to 120°C
  • Dimensions: 0.669” L x 0.610” W (17.00mm x 15.50mm)
  • Purpose: Reduce electromagnetic interference (EMI) and radio frequency interference (RFI)
