OHD3-45M Real Image
Same model may have multiple batches, images only for reference.

OHD3-45M

Part No OHD3-45M
Manufacturer Kemet
Catalog Temperature Sensors - Thermostats - Mechanical
Description THERMOSTAT 45DEG C SPST-NO MODUL
Datasheet
OHD3-45M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Temperature Sensors - Thermostats - Mechanical - Industrial
Mfr KEMET
Series OHD™ Thermal Guard
Package Tray
Product Status Active
Circuit SPST-NO
Switching Temperature 113°F (45°C)
Reset Temperature 95°F (35°C)
Current Rating - AC 0.3A (100V)
Current Rating - DC 0.3A (100V)
Tolerance ±9°F (±5°C)
Switching Cycles 100K
Termination Style Solder Lug
Mounting Type Chassis Mount
Package / Case Module
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 650211-OHD3-45M
Ultra Librarian 3D Model Ultra Librarian OHD3-45M CAD Model

Description

The OHD™ Thermal Guard (Part Number: 650211-OHD3-45M) is an industrial mechanical thermostat used in temperature sensing applications.

  • Circuit Configuration: SPST-NO
  • Switching Temperature: 113°F (45°C)
  • Reset Temperature: 95°F (35°C)
  • Current Rating (AC): 0.3A (100V)
  • Current Rating (DC): 0.3A (100V)
  • Mounting Method: Chassis Mount
  • Package: Module
  • Tolerance: ±9°F (±5°C)
  • Switching Cycle Rating: 100,000 cycles
  • Manufacturer: KEMET
  • Status: Active
