Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Relays
Manufacturer IXYS
Packaging Reel - TR
Status Active
Circuit DPST-NO/NC (1 Form A and B)
Output Type AC, DC
Max On Resistance 35 Ohm
Load Current 120mA
Voltage - Input 1.2VDC
Voltage - Load 0 to 350 V
Mounting SMD (SMT)
Termination Style Gull Wing
Case / Package 8-SMD
Relay Type Relay
Win Source Part Number 1051652-LBA110STR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LBA110STR CAD Model

Description

The IXYS relay is a DPST-NO/NC (1 Form A and B) circuit relay with a load current of 120mA and a voltage input of 1.2VDC.

  • Circuit: DPST-NO/NC (1 Form A and B)
  • Load Current: 120mA
  • Voltage Input: 1.2VDC
  • Voltage Load Range: 0 to 350 V
  • Maximum On Resistance: 35 Ohm
  • Relay Type: relay
  • Package: 8-SMD
  • Mounting Style: SMD (SMT)
  • Termination Style: gull wing
  • Status: active
