TLP172AM(TPL,E Real Image TLP172AM(TPL,E Real Image
Same model may have multiple batches, images only for reference.
TLP172AM(TPL,E Real Image TLP172AM(TPL,E Real Image
TLP172AM(TPL,E Real Image TLP172AM(TPL,E Real Image
Same model may have multiple batches, images only for reference.

TLP172AM(TPL,E

Part No TLP172AM(TPL,E
Manufacturer Toshiba Semiconductor and Storage
Catalog Solid State Relays
Description SSR RELAY SPST-NO 500MA 0-60V / Solid State SPST-NO (1 Form A) 6-SOP (0.179", 4.55mm), 4 Leads
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Toshiba Semiconductor and Storage
Series TLP172AM
Package Tape & Reel
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.27VDC
Voltage - Load 0 V ~ 60 V
Load Current 500 mA
On-State Resistance (Max) 2 Ohms
Termination Style Gull Wing
Package / Case 6-SOP (0.179", 4.55mm), 4 Leads
Supplier Device Package 6-SO, 4 Lead
Base Product Number TLP172
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 899956-TLP172AM(TPL,E
Ultra Librarian 3D Model Ultra Librarian TLP172AM(TPL,E CAD Model

Description

The TLP172AM is a solid state relay from Toshiba Semiconductor and Storage.

  • Series: TLP172AM
  • Termination Style: Gull Wing
  • Package: 6-SOP, 4 Leads
  • Mounting: Surface Mount
  • Voltage Input: 1.27VDC
  • Output Type: AC and DC
  • Circuit Configuration: SPST-NO (1 Form A)
  • On-State Resistance: 2 Ohms (Maximum)
  • Load Current: 500 mA
  • Load Voltage Range: 0 V to 60 V
