IR25602STRPBF

Name: IR25602STRPBF
Brand: Infineon Technologies
SKU: 604003
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IR25602STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	Half-Bridge Driver \| IC HALF BRIDGE DRIVER 8SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel
Driven Configuration	Half-Bridge
Channel Type	Synchronous
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage (V)	10V ~ 20V
Logic Voltage - VIL, VIH	0.8V, 3V
Current - Peak Output (Source, Sink)	210mA, 360mA
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise / Fall Time	100ns, 50ns
Temperature Range - Operating	-40°C ~ 150°C
Mounting Style	SMD
Manufacturer Package	8-SOIC
Supplier Device Package	8-SOIC
Family Part Number	IR25602SPBF
Manufacturer Pack Quantity	1
MSL Level	2 (1 Year)
Win Source Part Number	1186691-IR25602STRPBF
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IR25602STRPBF CAD Model

Description

This electronic component is manufactured by Infineon Technologies and has a Win Source Part Number of 1186691-IR25602STRPBF.

Category: Integrated Circuits
Packaging: Reel
Mounting Style: SMD
Channel Type: Synchronous
Input Type: Non-Inverting
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT and N-Channel MOSFET
Logic Voltage VIL: 0.8V
Logic Voltage VIH: 3V
Peak Output Current Source: 210mA
Peak Output Current Sink: 360mA
High Side Voltage (Bootstrap): 600V
Supplier Device Package: 8-SOIC
Supply and Demand Status: Balanced
