FT2232D-REEL - Dual USB UART/FIFO IC

From FTDI, Future Technology Devices International Ltd, the FT2232D-REEL is a versatile, high-quality dual USB to serial UART (Universal Asynchronous Receiver/Transmitter) or FIFO (First In, First Out) interface IC. This integrated circuit provides the perfect solution for applications requiring simultaneous USB to UART/FIFO conversion for efficient communication with a microcontroller or other serial devices.

Key Features:

• Dual Multi-Protocol Synchronous Serial Engine (MPSSE): The FT2232D-REEL is capable of facilitating serial communication with a variety of interfaces, including JTAG, I2C, SPI, and bit-bang mode, thanks to its dual MPSSE.
• USB 2.0 Full-Speed Compatibility: This device supports USB 2.0 full-speed operation at 12 Mbps, ensuring fast data transfer rates for applications requiring high-speed serial communication.
• Integrated EEPROM: For storing device descriptors and CBUS I/O configuration, the FT2232D-REEL includes an integrated EEPROM, reducing external component count and simplifying design.
• Flexible Clocking Options: It provides a variety of clocking options, including a 6 MHz crystal, an external oscillator, or a 48 MHz clock from the USB host, catering to diverse design requirements.
• Asynchronous and Synchronous Bit Bang Mode Interface: The device offers additional flexibility with its asynchronous and synchronous bit bang mode interface options, enabling a wide range of applications.

Applications:

The FT2232D-REEL is ideal for various applications, such as:

• USB to Dual-Channel Serial Converters
• USB Dual-Channel JTAG Interfaces
• USB to SPI/I2C Solutions
• Flash Programming Interfaces
• Industrial Control Interfaces

The FT2232D-REEL comes in a compact Reel package, making it suitable for mass production and automated assembly processes. With its advanced features, this device provides a turnkey solution for developers looking to integrate USB connectivity with minimal design effort.
