CTX2-3P-R Cooper Bussmann, Inc.
Same model may have multiple batches, images only for reference.

CTX2-3P-R

Part No CTX2-3P-R
Manufacturer Eaton Bussmann
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 1.85UH SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Arrays, Signal Transformers
Mfr Eaton Bussmann
Series Econo-Pac™
Package Tape & Reel
Product Status Active
Number of Coils 2
Inductance - Connected In Parallel 1.85 µH
Inductance - Connected In Series 7.4 µH
Tolerance ±20%
Current Rating - Parallel 4.6 A
Current Rating - Series 2.3 A
DC Resistance (DCR) - Parallel 11mOhm Max
DC Resistance (DCR) - Series 45mOhm Max
Shielding Unshielded
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.550" L x 0.550" W (13.97mm x 13.97mm)
Height 0.190" (4.83mm)
Standard Package 800 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 580987-CTX2-3P-R
Ultra Librarian 3D Model Ultra Librarian CTX2-3P-R CAD Model

Description

The Econo-Pac™ series inductor array is a versatile component for various electronic applications.

  • Size: 0.550" L x 0.550" W (13.97mm x 13.97mm)
  • Type: Unshielded
  • Mounting: Surface mount
  • Coils: Two
  • Inductance (Series): 7.4 µH
  • Inductance (Parallel): 1.85 µH
  • Current Rating (Parallel): 4.6 A
  • Current Rating (Series): 2.3 A
  • DC Resistance (DCR) Parallel: 11mOhm max
  • DC Resistance (DCR) Series: 45mOhm max
  • Temperature Range: -40°C to 85°C
  • Package: 800 pieces
  • Tolerance: ±20%
  • Manufacturer: Eaton Bussmann
