MGA-545P8-TR1 real image MGA-545P8-TR1 real image 2 MGA-545P8-TR1 label picture
Same model may have multiple batches, images only for reference.
MGA-545P8-TR1 real image MGA-545P8-TR1 real image 2 MGA-545P8-TR1 label picture
MGA-545P8-TR1 real image MGA-545P8-TR1 real image 2 MGA-545P8-TR1 label picture
Same model may have multiple batches, images only for reference.

MGA-545P8-TR1

Part No MGA-545P8-TR1
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC AMP RFIC GAAS 5.8GHZ 8-LPCC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 50MHz to 7GHz
P1dB 21.3dBm (134.9mW)
Gain 11.5dB
Noise Figure 2.9dB
RF Type WLL, WLAN
Supply Voltage - Operating 3.3V
Operating Supply Current 135mA
Test Frequency 3GHz
Case / Package 8-LPCC (2x2)
Win Source Part Number 058479-MGA-545P8-TR1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MGA-545P8
Introduction Date April 01, 2004
ECCN 5A991.g
Country of Origin China, Malaysia
Estimated EOL Date Obsolete
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MGA-545P8-TR1 CAD Model

Description

The Broadcom Limited MGA-545P8 RF Amplifier is a high-performance amplifier designed for use in WLL and WLAN applications.

  • Frequency Range: 50MHz to 7GHz
  • Gain: 11.5dB
  • Noise Figure: 2.9dB
  • P1dB: 21.3dBm (134.9mW)
  • Package: 8-LPCC (2x2)
  • Operating Voltage: 3.3V
  • Current: 135mA
  • Usage: Common-used part with high popularity and balanced supply and demand status
