HDSP-521A Broadcom Limited – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HDSP-521A

Part No HDSP-521A
Manufacturer Broadcom Limited
Catalog LED Character and Numeric
Description DISPLAY 7SEG 0.56\
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Characters 2
Size / Dimension 0.732" H x 0.984" W x 0.315" D (18.60mm x 25.00mm x 8.00mm)
Digit/Alpha Size 0.56" (14.22mm)
Display Type 7-Segment
Common Pin Common Anode
Color Red
Voltage - Forward (Vf) (Typ) 1.85V
Current - Test 20mA
Millicandela Rating 6.5mcd
Wavelength - Peak 660nm
Power Dissipation (Max) 30mW
Case / Package 18-DIP (0.600\
Package Tube
Supply and Demand Status Limited
Win Source Part Number 1565669-HDSP-521A
Ultra Librarian 3D Model Ultra Librarian HDSP-521A CAD Model

Description

N
