HCPL-060L-060E Real Image HCPL-060L-060E real image
Same model may have multiple batches, images only for reference.
HCPL-060L-060E Real Image HCPL-060L-060E real image
HCPL-060L-060E Real Image HCPL-060L-060E real image
Same model may have multiple batches, images only for reference.

HCPL-060L-060E

Part No HCPL-060L-060E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPN COLLECTOR 8SO / High Speed LVTTL Compatible 3.3 Volt Optocouplers
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Broadcom Limited
Packaging Tube
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Current - Output / Channel 50mA
Data Rate 15MBd
Propagation Delay tpLH / tpHL (Maximum) 75ns, 75ns
Rise / Fall Time (Typ) 24ns, 10ns
Voltage - Forward (Vf) (Typ) 1.5V
Current - DC Forward (If) (Maximum) 20mA
Supply Voltage (V) 2.7V ~ 3.6V, 4.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO Tall
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 811443-HCPL-060L-060E
Ultra Librarian 3D Model Ultra Librarian HCPL-060L-060E CAD Model

Description

The Broadcom Limited 811443-HCPL-060L-060E is a high-performance electronic component.

  • Output Type: Open Collector, Schottky Clamped
  • Data Rate: 15MBd
  • Supply and Demand: Limited
  • Manufacturer Pack Quantity: 100
  • Voltage Isolation: 3750Vrms
  • Common-Mode Transient Immunity: 10kV/µs
  • Operating Temperature: -40°C to 85°C
  • Propagation Delay tpLH / tpHL (Maximum): 75ns, 75ns
