ALM-2812-TR1G real image ALM-2812-TR1G label picture
Same model may have multiple batches, images only for reference.
ALM-2812-TR1G real image ALM-2812-TR1G label picture
ALM-2812-TR1G real image ALM-2812-TR1G label picture
Same model may have multiple batches, images only for reference.

ALM-2812-TR1G

Part No ALM-2812-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC AMP LNA WLAN DUAL 12MCOB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 2.4GHz to 2.5GHz, 4.9GHz to 6GHz
P1dB -5.8dBm (0.3mW)
Gain 16.7dB
Noise Figure 0.8dB
RF Type WLAN
Supply Voltage - Operating 3.6V
Operating Supply Current 15mA
Test Frequency 2.45GHz
Case / Package 12-MCOB (3x3)
Win Source Part Number 078017-ALM-2812-TR1G
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian ALM-2812-TR1G CAD Model

Description

Features and Benefits:
  • Low current consumption for energy efficiency
  • Excellent thermal stability
  • High gain across wide bandwidth
Applications:
  • Mobile communication devices
  • Base stations
  • Broadband systems

The ALM-2812-TR1G offers a blend of energy efficiency and high performance, making it an ideal choice for mobile and stationary communication devices. Its superior thermal stability ensures reliable operation in various environmental conditions.
