ACPL-M483-500E Real Image ACPL-M483-500E Real Image
Same model may have multiple batches, images only for reference.
ACPL-M483-500E Real Image ACPL-M483-500E Real Image
ACPL-M483-500E Real Image ACPL-M483-500E Real Image
Same model may have multiple batches, images only for reference.

ACPL-M483-500E

Part No ACPL-M483-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV PUSH PULL 5SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Broadcom Limited
Packaging Reel
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Min) 30kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 50mA
Propagation Delay tpLH / tpHL (Maximum) 120ns, 120ns
Rise / Fall Time (Typ) 6ns, 6ns
Voltage - Forward (Vf) (Typ) 1.5V
Current - DC Forward (If) (Maximum) 10mA
Supply Voltage (V) 4.5V ~ 30V
Temperature Range - Operating -40°C ~ 105°C
Mounting Style SMD
Manufacturer Package 6-SOIC, 5 Leads
Supplier Device Package 5-SO
Manufacturer Pack Quantity 1,500
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 801386-ACPL-M483-500E
Ultra Librarian 3D Model Ultra Librarian ACPL-M483-500E CAD Model

Description

The 801386-ACPL-M483-500E is a push-pull, totem pole output device from Broadcom Limited.

  • Mounting Style: SMD
  • Input Type: DC
  • Voltage-Forward (Vf) (Typ): 1.5V
  • Rise/Fall Time (Typ): 6ns
  • Current-Output/Channel: 50mA
  • Channels: 1
  • Voltage-Isolation: 3750Vrms
  • Inputs-Side 1/Side 2: 1/0
  • Common-Mode Transient Immunity (Min): 30kV/μs
  • Supplier Device Package: 5-SO
  • Operating Temperature Range: -40°C to 105°C
  • Manufacturer Package: 6-SOIC, 5 Leads
  • Current-DC Forward (If) (Maximum): 10mA
  • Propagation Delay tpLH/tpHL (Maximum): 120ns
  • Manufacturer Pack Quantity: 1,500
  • MSL Level: 1 (unlimited)
  • Supply Voltage (V): 4.5V to 30V
