CDSOT23-SM712 Bourns Inc. CDSOT23-SM712 Real Image CDSOT23-SM712 label picture CDSOT23-SM712 real image3023 CDSOT23-SM712 real image3024 CDSOT23-SM712 real image3025 CDSOT23-SM712 real image3026 CDSOT23-SM712 real image3027 CDSOT23-SM712 real image3028 CDSOT23-SM712 Real Image1 CDSOT23-SM712 Real Image2 CDSOT23-SM712 Real Image3 CDSOT23-SM712 Real Image4 CDSOT23-SM712 Real Image5 CDSOT23-SM712 Real Image6 CDSOT23-SM712 Real Image7 CDSOT23-SM712 Real Image8 CDSOT23-SM712 Real Image9
Same model may have multiple batches, images only for reference.
CDSOT23-SM712 Bourns Inc. CDSOT23-SM712 Real Image CDSOT23-SM712 label picture CDSOT23-SM712 real image3023 CDSOT23-SM712 real image3024 CDSOT23-SM712 real image3025 CDSOT23-SM712 real image3026 CDSOT23-SM712 real image3027 CDSOT23-SM712 real image3028 CDSOT23-SM712 Real Image1 CDSOT23-SM712 Real Image2 CDSOT23-SM712 Real Image3 CDSOT23-SM712 Real Image4 CDSOT23-SM712 Real Image5 CDSOT23-SM712 Real Image6 CDSOT23-SM712 Real Image7 CDSOT23-SM712 Real Image8 CDSOT23-SM712 Real Image9
CDSOT23-SM712 Bourns Inc. CDSOT23-SM712 Real Image CDSOT23-SM712 label picture CDSOT23-SM712 real image3023 CDSOT23-SM712 real image3024 CDSOT23-SM712 real image3025 CDSOT23-SM712 real image3026 CDSOT23-SM712 real image3027 CDSOT23-SM712 real image3028 CDSOT23-SM712 Real Image1 CDSOT23-SM712 Real Image2 CDSOT23-SM712 Real Image3 CDSOT23-SM712 Real Image4 CDSOT23-SM712 Real Image5 CDSOT23-SM712 Real Image6 CDSOT23-SM712 Real Image7 CDSOT23-SM712 Real Image8 CDSOT23-SM712 Real Image9
Same model may have multiple batches, images only for reference.

CDSOT23-SM712

Part No CDSOT23-SM712
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 7VWM/12VWM SOT23
Datasheet
CDSOT23-SM712 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 2
STAND-OFF Voltage (Vwm) 7V (Max), 12V (Max)
Minimum Breakdown Voltage 7.5V, 13.3V
Max Clamping Voltage 14V, 26V
Peak Pulse Current(Ippm) 17A (8/20μs)
Power Dissipation - Pd 400W
Applications General Purpose
Capacitance @ Frequency 75pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 000239-CDSOT23-SM712
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Communications & Networking
Family Name CDSOT23-SM712
Introduction Date July 02, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian CDSOT23-SM712 CAD Model

Description

CDSOT23-SM712 TVS Diode

The CDSOT23-SM712 is a high-performance Transient Voltage Suppressor (TVS) diode designed to safeguard electronic devices from ESD and electrical overstress. This component is crucial in maintaining the reliability and longevity of sensitive electronics.

  • Applications:
    • Data line protection
    • Automotive electronics
    • Telecommunications equipment
  • Features and Benefits:
    • Low clamping voltage for enhanced protection
    • Bi-directional protection capability
    • Compact SOT-23 package for space-constrained designs

This diode is ideal for applications requiring reliable and robust protection against voltage transients, ensuring efficient performance in various electronic setups.
