Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tray
Status Obsolete(EOL)
Type Linear
Number of Outputs 16
Operating Input Voltage(Min) 10.8V
Maximum Supply Voltage 13.2V
Frequency 20MHz
Dimming PWM
Applications Backlight, Lighting
Temperature Range - Operating -40°C to 105°C (TA)
Mounting SMD (SMT)
Case / Package 64-TQFN (9x9)
Win Source Part Number 059562-MSL2160DQ
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MSL2160DQ CAD Model

Description

The Microchip Technology 20MHz Linear Integrated Circuit is a high-quality electronic component designed for backlight and lighting applications.

  • Maximum supply voltage: 13.2V
  • Operating input voltage: 10.8V
  • Case/Package: 64-TQFN (9x9)
  • Operating Temperature: -40°C to 105°C (TA)
  • Outputs: 16
  • Dimming: PWM
  • Status: This IC is now obsolete (EOL)
  • Popularity: medium
  • Alternative parts: LM3450AMTX/NOPB, ISL1904FAZ-T, and ISL1903FAZ
