AD9915BCPZ

Part No AD9915BCPZ
Manufacturer Analog Devices Inc.
Catalog Interface - Direct Digital Synthesis (DDS)
Description 2.5 GSPS Direct Digital Synthesizer with 12-Bit DAC | IC DDS 16B 2.5GHZ 88LFCSP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tray
Resolution (Bits) 12 b
Master fclk 2.5GHz
Tuning Word Width (Bits) 32 b
Supply Voltage (V) 1.8V, 3.3V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 88-VFQFN Exposed Pad, CSP
Supplier Device Package 88-LFCSP-VQ (12x12)
Family Part Number AD9915
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1139355-AD9915BCPZ
Manufacturer Homepage www.analog.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian AD9915BCPZ CAD Model

Description

The AD9915BCPZ is a state-of-the-art Direct Digital Synthesizer (DDS) component designed and manufactured by Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing (DSP) integrated circuits. This device stands out for its exceptional performance and versatility, making it an ideal choice for a wide range of applications including communications, instrumentation, and radar systems.

Key Features:

  • High-Speed Operation: The AD9915BCPZ boasts a maximum clock rate of 2.5 GHz, enabling the generation of high-frequency signals with fine frequency resolution.
  • High Resolution: With a 32-bit frequency tuning word, users can achieve extremely fine frequency tuning granularity, making it suitable for precision applications.
  • Programmable Modulation: The device supports advanced modulation capabilities, including amplitude, phase, and frequency modulation, providing flexibility in signal generation.
  • Integrated DAC: It incorporates a high-speed 14-bit digital-to-analog converter (DAC), ensuring high-quality analog signal output with a low noise floor.
  • Multiple Synthesis Modes: The AD9915BCPZ offers linear and nonlinear frequency sweep modes, as well as user-defined chirp functionality for complex waveform generation.

Technical Specifications:

Parameter Value
Clock Rate Up to 2.5 GHz
Resolution 32-bit frequency tuning word
DAC Resolution 14-bit
Package 88-LFCSP (LFCSP-88)

The AD9915BCPZ is housed in a compact 88-lead LFCSP (LFCSP-88) package, making it suitable for space-constrained applications while still delivering robust performance. Its advanced features and capabilities make it a top choice for designers seeking a high-frequency, high-resolution DDS solution.

For detailed information, datasheets, and support resources, visit the Analog Devices Inc. website or contact their support team for assistance in integrating the AD9915BCPZ into your next project.
