AD8147ACPZ-R7

Part No AD8147ACPZ-R7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Video Amps and Modules
Description Triple Differential Driver for Wideband Video
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Applications Differential
Output Type Differential
Number of Circuits 3
-3db Bandwidth 780MHz
SR - Slew Rate 3000 V/μs
Operating Supply Current 61.5mA
Output Current per Channel 87mA
Dual Supply Voltage (±) 4.5 V ~ 11 V, ±2.25 V ~ 5.5 V
Mounting SMD
Package 24-WFQFN Exposed Pad, CSP
Manufacturer Package 24-LFCSP-WQ (4x4)
Win Source Part Number 1138276-AD8147ACPZ-R7
Manufacturer Homepage www.analog.com
Family Name AD8147
Introduction Date December 01, 2006
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD8147ACPZ-R7 CAD Model

Description

Product Overview: AD8147ACPZ-R7 from Analog Devices Inc.

The AD8147ACPZ-R7 is a high-performance, triple differential driver specifically designed for the transmission of high-speed signals over twisted pair cables. Manufactured by Analog Devices Inc., a leader in precision high-performance electronics, this driver is ideal for a wide range of applications including video broadcasting, surveillance systems, and automotive infotainment systems.

Key Features

  • High-Speed Performance: The AD8147ACPZ-R7 is capable of driving high-speed signals, ensuring minimal distortion and excellent signal integrity over long cable distances.
  • Triple Differential Driver: This device features three independent differential drivers, making it suitable for RGB or YPbPr video signals as well as other applications requiring multiple high-speed data channels.
  • Adjustable Gain: The gain of the AD8147ACPZ-R7 can be adjusted via external resistors, providing flexibility to match the cable length and signal requirements.
  • Low Power Consumption: Designed with power efficiency in mind, it consumes low power, which is crucial for portable and automotive applications where power conservation is key.
  • Wide Supply Range: The device operates over a wide supply voltage range, accommodating various system design requirements.
  • Integrated Protection: The AD8147ACPZ-R7 includes integrated short-circuit and over-temperature protection, enhancing the reliability and longevity of the system.

Package and Quality

The AD8147ACPZ-R7 is offered in a compact 48-lead LFCSP (Lead Frame Chip Scale Package) that is designed for space-constrained applications. The package is RoHS compliant and lead-free, ensuring it meets modern environmental standards. Analog Devices Inc. is known for its commitment to quality, and this product is no exception, undergoing rigorous testing to ensure high reliability and performance.

Applications

  • High-Definition Video Transmission
  • Automotive Infotainment and Camera Systems
  • Industrial Video Processing
  • Medical Imaging Equipment
  • Surveillance Systems

In summary, the AD8147ACPZ-R7 from Analog Devices Inc. is a versatile and reliable choice for any application requiring the transmission of high-speed differential signals over twisted pair cables. Its robust design and advanced features make it an essential component for designers looking to optimize their high-speed signal chain solutions.
