The AD5790BCPZ is a state-of-the-art, high precision 20-bit digital-to-analog converter (DAC) designed by Analog Devices Inc. This premium product offers the ultimate in accuracy and stability, making it an ideal choice for applications demanding the highest precision, such as medical instrumentation, test and measurement equipment, and high-end scientific and aerospace instrumentation.

Key Features:

• 20-Bit Resolution: The AD5790 boasts a full 20-bit resolution with no missing codes, ensuring the finest level of granularity in signal conversion.
• Integrated Output Amplifier: An on-chip output amplifier facilitates a rail-to-rail output swing, providing a wide dynamic range for various applications.
• Low Noise and High Stability: The device features exceptional low noise performance and high stability, which is critical for precision applications.
• Programmable Settling Time: Users can program the settling time to optimize the speed versus performance ratio as per their specific needs.
• Flexible Reference Input: The DAC supports a flexible reference input range, accommodating a variety of reference voltages to suit different application requirements.
• Serial Interface: It comes with a 3-wire serial interface that is compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards, allowing for easy integration into digital systems.

Applications:

• Medical Instrumentation
• Test and Measurement
• High-end Scientific Research
• Aerospace and Defense Systems
• Industrial Control Systems

Product Specifications:

The AD5790BCPZ operates with a single supply voltage from 4.75 V to 5.25 V and is specified over the industrial temperature range of -40°C to +85°C. It comes in a compact, surface-mount LFCSP (Lead Frame Chip Scale Package) that is RoHS compliant and designed for optimized footprint and performance.

Quality and Reliability:

Analog Devices Inc. is renowned for its commitment to high-quality products, and the AD5790BCPZ is no exception. It is built with the highest quality materials and has undergone rigorous testing to ensure performance and reliability in the most demanding conditions.

For detailed technical specifications, application notes, and support resources, visit the Analog Devices Inc. website or contact their customer support team.
