77311-101-36

Get a Quote

Part No	77311-101-36
Manufacturer	Amphenol
Catalog	Rectangular Connectors
Description	CONN HEADER VERT 36POS 2.54MM / Connector Header Through Hole 36 position 0.100" (2.54mm)
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors>Headers, Male Pins
Manufacturer	Amphenol ICC (FCI)
Packaging	Bulk
Product Status	Obsolete
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	36
Number of Rows	1
Number of Positions Loaded	All
Style	Board to Board
Shrouding	Unshrouded
Mounting	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.230" (5.84mm)
Contact Length - Post	0.095" (2.41mm)
Overall Contact Length	0.425" (10.80mm)
Insulation Height	0.100" (2.54mm)
Contact Shape	Square
Contact Finish - Mating	Gold or Gold, GXT™
Contact Finish Thickness - Mating	30.0µin (0.76µm)
Contact Finish - Post	Tin-Lead
Contact Material	Phosphor Bronze
Insulation Material	Thermoplastic
Temperature Range - Operating	-65°C ~ 125°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	3A per Contact
Contact Finish Thickness - Post	150.0µin (3.81µm)
Base Product Number	77311
RoHS Status	RoHS non-compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Standard Package	100
Win Source Part Number	1332848-77311-101-36
Ultra Librarian 3D Model	Ultra Librarian 77311-101-36 CAD Model

Description

This is a 36 position connector header with male pins.

Positions: 36
Packaging: Bulk
Mounting Type: Through Hole
Pitch: 0.100" (2.54mm)
Voltage Rating: -
Current Rating: 3A per contact
Contact Finish Mating: Gold
Contact Finish Post: Tin-Lead
Contact Finish Mating Thickness: 30.0µin (0.76µm)
Contact Finish Post Thickness: 150.0µin (3.81µm)
Insulation Material: Thermoplastic
Insulation Color: Black
ECCN: EAR99
REACH: Unaffected
HTSUS Code: 8536.69.4040
Other Part Numbers: 609-5020-1, 609-5020-2, 2266-10132797-011100LF, 609-5020-6
Base Product Number: 77311
Product Status: Obsolete
RoHS Compliant: No
