MS27505E25B4P Real Image
Same model may have multiple batches, images only for reference.

MS27505E25B4P

Part No MS27505E25B4P
Manufacturer Amphenol Aerospace Operations
Catalog Circular Connectors
Description CONN RCPT 56POS BOX MNT W/PINS / Conn Circular PIN 56 POS Crimp ST Box Mount 56 Terminal 1 Port
Datasheet
MS27505E25B4P Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol Aerospace Operations
Series Military, MIL-DTL-38999 Series I
Packaging Bulk
Connector Type Receptacle, Male Pins
Number of Positions 56
Shell Size - Insert 25-4
Mounting Panel Mount, Flange
Termination Crimp
Fastening Type Bayonet Lock
Orientation N (Normal)
Ingress Protection Environment Resistant
Shell Material, Finish Aluminum, Olive Drab Cadmium Plated
Contact Finish Gold
Voltage Rating DC 600VAC, 850VDC
Current Rating 7.5A, 13A
Contact Finish Thickness 50μin (1.27μm)
Operating Temperature Range -65°C ~ 175°C
Win Source Part Number 789486-MS27505E25B4P
Popularity Medium
Supply and Demand Status Limited
Family Name MS27505
Introduction Date October 15, 2006
ECCN EAR99
Country of Origin China, Germany, Mexico
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MS27505E25B4P CAD Model

Description

The 789486-MS27505E25B4P connector is a military-grade connector manufactured by Amphenol Aerospace Operations.

  • Series: MIL-DTL-38999 Series I
  • Packaging: Bulk
  • Positions: 56
  • Operating Temperature: -65°C to 175°C
  • Connector Type: Receptacle, Male Pins
  • Termination: Crimp
  • Fastening: Bayonet Lock
  • Contact Finish: Gold
  • Contact Finish Thickness: 50μin (1.27μm)
  • Current Rating: 7.5A, 13A
  • Ingress Protection: Environment-Resistant
  • Orientation: N (Normal)
  • Mounting Type: Panel Mount, Flange Mount
  • Shell Size Insert: 25-4
  • Voltage Rating DC: 600VAC, 850VDC
  • Introduction Date: October 15, 2006
  • Estimated EOL Date: 2027
  • Supply and Demand Status: Limited
  • ECCN: EAR99
  • Manufacturer Location: China, Germany, Mexico
