EVB-EN2342QI Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Altera
Series Enpirion
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 0.75 V ~ 5 V
Output Current 4A
Voltage - Input 4.5 V ~ 14 V
Regulator Topology Buck
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part EN2342QI
Win Source Part Number 773782-EVB-EN2342QI
Popularity Medium
Supply and Demand Status Limited
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian EVB-EN2342QI CAD Model

Description

The Altera EVB-EN2342QI is a development board designed for use with the EN2342QI regulator.

  • Output Voltage Range: 0.75 V to 5 V
  • Input Voltage Range: 4.5 V to 14 V
  • Outputs: 1 (non-isolated)
  • Applications: DC/DC, Step-down
