The TPS61120EVM-205 from Texas Instruments is a comprehensive evaluation module (EVM) designed to help engineers and designers evaluate the performance and capabilities of the TPS61120 integrated circuit. This high-efficiency, synchronous, step-up converter is part of TI's extensive portfolio of power management solutions and is particularly well-suited for portable applications that require a compact, efficient power source.

The TPS61120EVM-205 is a fully assembled and tested circuit board that demonstrates the functionality of the TPS61120 in a typical boost converter application. It operates over a wide input voltage range of 2.0V to 6.5V, making it versatile for various battery technologies, including Li-ion, NiCd, and NiMH. With its adjustable output voltage up to 28V, this EVM can be used to power OLEDs, LEDs, and other devices requiring a higher voltage than the battery can provide.

One of the key features of the TPS61120 is its integrated synchronous rectifier, which enhances efficiency by reducing the power loss associated with diode rectifiers. This feature is particularly beneficial in battery-powered applications where maximizing battery life is critical. Additionally, the TPS61120 offers a fixed switching frequency of 1.2MHz, allowing for the use of small external components, further minimizing the solution size and the overall footprint on the PCB.

The TPS61120EVM-205 also includes numerous safety features such as over-temperature protection, over-voltage protection, and under-voltage lockout, ensuring reliable operation under various conditions. Its low quiescent current contributes to extended battery life when the device is in standby mode.

This evaluation module is an indispensable tool for engineers looking to quickly prototype and test designs that incorporate the TPS61120 IC. It comes with all necessary documentation, including schematics, a bill of materials, and a user guide, to facilitate a smooth and efficient evaluation process.

Whether you're developing power supplies for handheld devices, portable media players, or other mobile applications, the TPS61120EVM-205 provides a convenient and effective platform for testing and validating your power design with the TPS61120 IC.
