XC3S500E-4FTG256I Real Image XC3S500E-4FTG256I Real Image1 XC3S500E-4FTG256I Real Image2 XC3S500E-4FTG256I Real Image3
Same model may have multiple batches, images only for reference.
XC3S500E-4FTG256I Real Image XC3S500E-4FTG256I Real Image1 XC3S500E-4FTG256I Real Image2 XC3S500E-4FTG256I Real Image3
XC3S500E-4FTG256I Real Image XC3S500E-4FTG256I Real Image1 XC3S500E-4FTG256I Real Image2 XC3S500E-4FTG256I Real Image3
Same model may have multiple batches, images only for reference.

XC3S500E-4FTG256I

Part No XC3S500E-4FTG256I
Manufacturer Xilinx Inc.
Catalog Embedded - FPGAs (Field Programmable Gate Array)
Description IC FPGA 190 I/O 256FTBGA / FPGA Spartan®-3E Family 500K Gates 10476 Cells 572MHz 90nm Technology 1.2V 256-Pin FTBGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Xilinx Inc.
Status Active
Number of LABs/CLBs 1164
Number of Logic Elements/Cells 10476
Total RAM Bits 368640
Number of I/O 190
Number of Gates 500000
Supply Voltage - Operating 1.14 V to 1.26 V
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 100°C (TJ)
Case / Package 256-FTBGA (17x17)
Win Source Part Number 405306-XC3S500E-4FTG256I
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name XC3S500E
Introduction Date January 05, 1999
ECCN EAR99
Country of Origin Philippines, Republic of Korea, Taiwan, Singapore
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian XC3S500E-4FTG256I CAD Model

Description

The XC3S500E-4FTG256I is a surface mount device with 190 I/Os, 1164 LABs/CLBs, 10476 Logic Elements/Cells, 500000 gates, and 368640 RAM bits from Xilinx Inc.

  • I/Os: 190
  • LABs/CLBs: 1164
  • Logic Elements/Cells: 10476
  • Gates: 500000
  • RAM bits: 368640
  • Voltage Range: 1.14V to 1.26V
  • Temperature Range: -40°C to 100°C
  • Category: Integrated Circuits
  • Status: active
