7448680180 Wurth Electronics Inc – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

7448680180

Part No 7448680180
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 150UH 20A 2LN TH
Datasheet
7448680180 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 150 µH @ 10 kHz
Current Rating (Max) 20A
DC Resistance (DCR) (Max) 1.9mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 115°C
Mounting Type Through Hole
Size / Dimension 1.083" L x 0.984" W (27.51mm x 24.99mm)
Height (Max) 0.472" (11.99mm)
Case / Package Horizontal, 4 PC Pad
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1507210-7448680180
Ultra Librarian 3D Model Ultra Librarian 7448680180 CAD Model

Description

N
