Same model may have multiple batches, images only for reference.
744281101 Real Image
Same model may have multiple batches, images only for reference.

744281101

Part No 744281101
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 100UH 350MA 2LN 50K OHM SMD / 100 μH @ 100 kHz 2 Line Common Mode Choke Surface Mount 50 kOhms @ 7 MHz 350mA DCR 950mOhm
Datasheet
744281101 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - Common Mode Chokes
Mfr Wurth Electronics Inc
Series WE-SCC
Package Tape & Reel
Product Status Active
Filter Type Power, Signal Line
Number of Lines 2
Impedance @ Frequency 50 kOhms @ 7 MHz
Inductance @ Frequency 100 µH @ 100 kHz
Current Rating (Max) 350mA
DC Resistance (DCR) (Max) 950mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Size / Dimension 0.287" L x 0.287" W (7.30mm x 7.30mm)
Height (Max) 0.189" (4.80mm)
Package / Case Horizontal, 4 PC Pad
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 857316-744281101
Ultra Librarian 3D Model Ultra Librarian 744281101 CAD Model

Description

The WE-SCC is a common mode choke manufactured by Wurth Electronics Inc. It is designed for power and signal line filtering applications.

  • Voltage Rating: 80V DC
  • Current Rating: 350mA (Maximum)
  • Size: 0.287" L x 0.287" W (7.30mm x 7.30mm)
  • Height: 0.189" (4.80mm)
  • Package: Horizontal, 4 PC pad
  • Impedance: 50 kOhms @ 7 MHz
  • Inductance: 100 µH @ 100 kHz
  • DC Resistance (DCR): 950mOhm
  • Operating Temperature: -40°C to 125°C
