744253200 Wurth Electronics Inc – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

744253200

Part No 744253200
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 20UH 500MA 3LN SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Signal Line
Number of Lines 3
Inductance @ Frequency 20 µH @ 100 kHz
Current Rating (Max) 500mA
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Height (Max) 0.098" (2.50mm)
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1507232-744253200
Ultra Librarian 3D Model Ultra Librarian 744253200 CAD Model

Description
