RGF1M-E3/67A Vishay
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1000V (1kV)
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.3V @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 500ns
Current - Reverse Leakage @ Vr 5μA @ 1000V
Capacitance @ Vr, F 8.5pF @ 4V, 1MHz
Mounting SMD (SMT)
Case / Package DO-214BA (GF1)
Operating Temperature - Junction -65°C to 175°C
Win Source Part Number 102113-RGF1M-E3/67A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name RGF1M
Introduction Date June 24, 1998
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian RGF1M-E3/67A CAD Model

Description

This electronic component is manufactured by Vishay and is part of the RGF1M family.

  • Type: It is a standard SMD diode
  • Maximum DC Reverse Voltage: with a maximum DC reverse voltage of 1000V
  • Average Rectified Current: and an average rectified current of 1A.
  • Forward Voltage: The forward voltage is 1.3V @ 1A
  • Reverse Recovery Time: and the reverse recovery time is 500ns.
  • Current Leakage: The current leakage @ 1000V is 5μA
  • Capacitance: and the capacitance @ 4V and 1MHz is 8.5pF.
  • Operating Temperature: The operating temperature range is from -65°C to 175°C.
  • Status: This product is actively sold
  • Popularity: and has high popularity.
