Same model may have multiple batches, images only for reference.

MBR0520

Name: MBR0520
Brand: Yangzhou yangjie electronic co., ltd
SKU: 633233
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MBR0520
Manufacturer	Yangzhou yangjie electronic co., ltd
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 20V 500MA SOD123 / Diode 20 V 500mA Surface Mount SOD-123
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr	Yangzhou yangjie electronic co., ltd
Package	Tape & Reel
Product Status	Active
Technology	Schottky
Voltage - DC Reverse (Vr) (Max)	20 V
Current - Average Rectified (Io)	500mA
Voltage - Forward (Vf) (Max) @ If	450 mV @ 500 mA
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	100 µA @ 20 V
Capacitance @ Vr, F	30pF @ 4V, 1MHz
Mounting Type	Surface Mount
Package / Case	SOD-123
Supplier Device Package	SOD-123
Operating Temperature - Junction	-55°C ~ 150°C
Standard Package	3,000 pcs
REACH Status	REACH Unaffected
ECCN	EAR99
Win Source Part Number	633233-MBR0520
Ultra Librarian 3D Model	Ultra Librarian MBR0520 CAD Model

Alternative Products

Description

The 633233-MBR0520 is a Schottky diode rectifier designed for use in discrete semiconductor products.

Maximum Voltage Rating: 20V
Average Rectified Current: 500mA
Forward Voltage Drop: 450mV @ 500mA
Reverse Leakage Current: 100µA @ Maximum Reverse Voltage
Capacitance: 30pF @ 4V and 1MHz
Mounting Type: Surface Mountable
Package: SOD-123
Manufacturer: Yangzhou yangjie electronic co., ltd
Product Status: Active
