Same model may have multiple batches, images only for reference.

MAL219691112E3

Name: MAL219691112E3
Brand: Vishay
SKU: 1157597
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	MAL219691112E3
Manufacturer	Vishay
Catalog	Aluminum Capacitors
Description	CAP 4F -20% +80% 2.8V T/H / 4 F (EDLC) Supercapacitor 2.8 V Coin, Stacked Horizontal 5Ohm @ 1kHz 1000 Hrs @ 70°C
Datasheet	MAL219691112E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Electric Double Layer Capacitors (EDLC), Supercapacitors
Mfr	Vishay Beyschlag/Draloric/BC Components
Series	ENYCAP™ 196HVC
Package	Tray
Capacitance	4 F
Tolerance	-20%, +80%
Voltage - Rated	2.8 V
ESR (Equivalent Series Resistance)	5Ohm @ 1kHz
Lifetime @ Temp.	1000 Hrs @ 70°C
Termination	PC Pins
Mounting Type	Through Hole
Package / Case	Coin, Stacked Horizontal
Lead Spacing	0.201" (5.10mm)
Dimension	0.276" Dia x 0.197" L (7.00mm x 5.00mm)
Height - Seated (Max)	0.276" (7.00mm)
Temperature Range - Operating	-20°C ~ 70°C
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0020
Standard Package	800
Win Source Part Number	1157597-MAL219691112E3
Ultra Librarian 3D Model	Ultra Librarian MAL219691112E3 CAD Model

Description

The MAL219691112E3 is an electric double layer capacitor (EDLC) or supercapacitor that comes in a coin, stacked horizontal package.

Capacitance: 4F
Tolerance: -20%, +80%
Voltage Rating: 2.8V
ESR (Equivalent Series Resistance): 5Ohm @ 1kHz
Height: 0.276" (7.00mm)
Lead Spacing: 0.201" (5.10mm)
Standard Package: 800
Ideal for: Use in various electronic applications
