Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Siliconix
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 800V
Id - Continuous Drain Current 7.8A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 1.2Ohm at 4.7A, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 200nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 3100pF at 25V
Power Dissipation (Maximum) 190W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Supplier Device Package TO-247-3
Manufacturer Package TO-247-3
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Win Source Part Number 1187824-IRFPE50
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial, Safety
Ultra Librarian 3D Model Ultra Librarian IRFPE50 CAD Model

Description

This electronic component is a Vishay Siliconix MOSFET with an N-channel transistor polarity.

  • Mounting Style: through hole
  • Category: discrete semiconductor products
  • Supplier Device Package: TO-247-3
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Product Status: obsolete
  • Temperature Range: -55°C to 150°C
  • Manufacturer Package: TO-247-3
  • Power Dissipation (Maximum): 190W
  • Supply and Demand Status: limited
  • Manufacturer Pack Quantity: 500
  • MSL Level: 1 (Unlimited)
  • Vds - Drain-Source Breakdown Voltage: 800V
  • Id - Continuous Drain Current: 7.8A
  • Rds On (Maximum) @ Id, Vgs: 1.2Ohm @ 4.7A, 10V
  • Gate Source Voltage(th) (Maximum) @ Id: 4V @ 250μA
  • Gate Charge (Qg) (Maximum) @ Vgs: 200nC @ 10V
  • Gate Source Voltage (Maximum): ±20V
  • Input Capacitance (Ciss) (Maximum) @ Vds: 3100pF @ 25V
