IRF9610

Part No IRF9610
Manufacturer Vishay
Catalog FETs - Single
Description Power MOSFET(Vdss=-200V, Rds(on)=3.0ohm, Id=-1.8A) | MOSFET P-CH 200V 1.8A TO-220AB
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Siliconix
Packaging Tube
Status Obsolete
Transistor Polarity P-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 200V
Id - Continuous Drain Current 1.8A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 3Ohm at 900mA, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 11nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 170pF at 25V
Power Dissipation (Maximum) 20W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Supplier Device Package TO-220AB
Manufacturer Package TO-220-3
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Win Source Part Number 1187452-IRF9610
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian IRF9610 CAD Model

Description

IRF9610 from Vishay is a single MOSFET commonly considered for power switching and load-control tasks in analog and power-management designs. Engineers may evaluate this device for use in high-side switching, battery-powered equipment, DC power distribution, motor-related control stages, and general-purpose switching circuits where a discrete FET is preferred over an integrated solution. Its value lies in broad design familiarity, flexible use across repair and legacy maintenance programs, and suitability for engineers who need a recognizable discrete power transistor footprint in established designs. For new programs, component selection should include current manufacturer documentation, qualification requirements, and supply-chain review before release. Lifecycle status for IRF9610 is currently information not available, so procurement and sustaining teams should verify ongoing production directly with Vishay or authorized distributors. RoHS compliance status is also information not available from the provided input; engineers should confirm the latest environmental compliance declarations, datasheet, and material content documentation before production use.
