IHLP4040DZER1R0M11 Real Image IHLP4040DZER1R0M11 Real Image1 IHLP4040DZER1R0M11 Real Image2 IHLP4040DZER1R0M11 Real Image3 IHLP4040DZER1R0M11 Real Image4
Same model may have multiple batches, images only for reference.
IHLP4040DZER1R0M11 Real Image IHLP4040DZER1R0M11 Real Image1 IHLP4040DZER1R0M11 Real Image2 IHLP4040DZER1R0M11 Real Image3 IHLP4040DZER1R0M11 Real Image4
IHLP4040DZER1R0M11 Real Image IHLP4040DZER1R0M11 Real Image1 IHLP4040DZER1R0M11 Real Image2 IHLP4040DZER1R0M11 Real Image3 IHLP4040DZER1R0M11 Real Image4
Same model may have multiple batches, images only for reference.

IHLP4040DZER1R0M11

Part No IHLP4040DZER1R0M11
Manufacturer Vishay
Catalog Fixed Inductors
Description Inductor Power Shielded Wirewound 1uH 20% 100KHz Powdered Iron 25A 0.0025Ohm DCR 4040 T/R / FIXED IND 1UH 25A 2.5 MOHM SMD
Datasheet
IHLP4040DZER1R0M11 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Molded
Inductance 1μH
Tolerance ±20%
Current Rating 25A
Current - Saturation 20A
DC Resistance (DCR) 2.5 mOhm Max
Temperature Range - Operating -55°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.157" (4.00mm)
Win Source Part Number 017186-IHLP4040DZER1R0M11
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IHLP-4040DZ-11
Introduction Date October 17, 2006
ECCN EAR99
Country of Origin China, Israel, United States of America
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IHLP4040DZER1R0M11 CAD Model

Description

The Vishay 017186-IHLP4040DZER1R0M11 is a molded inductor with a current rating of 25A and an inductance of 1μH.

  • Tolerance: ±20%
  • DC Resistance: 2.5 mOhm Max
  • Supply and Demand: Currently in balance
