ICM1206ER102M Vishay – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ICM1206ER102M

Part No ICM1206ER102M
Manufacturer Vishay
Catalog Common Mode Chokes
Description CMC 230MA 2LN 1 KOHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 1 kOhms @ 100 MHz
Current Rating (Max) 230mA
DC Resistance (DCR) (Max) 1Ohm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Size / Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height (Max) 0.083" (2.10mm)
Case / Package Horizontal, 4 PC Pad
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1530555-ICM1206ER102M
Ultra Librarian 3D Model Ultra Librarian ICM1206ER102M CAD Model
