EMVE250ARA221MHA0G United Chemi-Con
Same model may have multiple batches, images only for reference.

EMVE250ARA221MHA0G

Part No EMVE250ARA221MHA0G
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 220UF 20% 25V SMD / 220 µF 25 V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr United Chemi-Con
Series Alchip™- MVE
Package Tape & Reel
Product Status Active
Capacitance 220 µF
Tolerance ±20%
Voltage - Rated 25 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 2000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 320 mA @ 120 Hz
Lead Spacing -
Size / Dimension 0.315" Dia (8.00mm)
Height - Seated (Max) 0.394" (10.00mm)
Surface Mount Land Size 0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1360323-EMVE250ARA221MHA0G
Ultra Librarian 3D Model Ultra Librarian EMVE250ARA221MHA0G CAD Model

Description

The 1360323-EMVE250ARA221MHA0G is an aluminum electrolytic capacitor from United Chemi-Con's Alchip™-MVE series.

  • Series: Alchip™-MVE
  • Mounting Type: Surface Mount
  • Capacitance: 220 µF
  • Voltage Rating: 25 V
  • Lifetime: 2000 hours @ 105°C
  • Application: General-Purpose
  • Ripple Current: 320 mA @ 120 Hz
  • Package: Radial, can - SMD
  • Size/Dimension: 0.315" diameter (8.00mm) with a height of 0.394" (10.00mm)
  • REACH: Unaffected
  • ECCN: EAR99
