TLP160G

Name: TLP160G
Brand: Toshiba Semiconductor and Storage
SKU: 370079
Availability: InStock
Rating: 4.85 (64 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP160G
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Triac, SCR Output
Description	Optocoupler Triac AC-OUT 1-CH 400V 4-Pin MFSOP / OPTOISOLATOR 2.5KV TRIAC 6MFSOP
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel - TR
Status	Active
Output Type	Triac
Zero Crossing Circuit	No
Number of Channels	1
Isolation Voltage	2500Vrms
Voltage - Off State	400V
Static dV/dt (Min)	200V/μs
Current - LED Trigger (Ift) (Max)	10mA
Current - On State (It (RMS)) (Max)	70mA
Current - Hold (Ih)	600μA (Typ)
Turn On Time	30μs
Forward Voltage	1.15V
Continuous forward current- Max	50mA
Temperature Range - Operating	-40°C to 100°C
Mounting	SMD (SMT)
Case / Package	6-MFSOP, 4 Lead
Approvals	UR
Win Source Part Number	092737-TLP160G
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	TLP160G
Introduction Date	February 27, 1998
ECCN	EAR99
Country of Origin	Japan
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian TLP160G CAD Model

Alternative Products

Description

The TLP160G is a Triac output optocoupler manufactured by Toshiba Semiconductor and Storage.

Voltage-Off State: 400V
Forward Voltage: 1.15V
Maximum Current-On State: 70mA
Current-Hold: 600μA (typ)
Zero-Crossing Circuit: Yes
Turn-On Time: 30μs
Package: 6-MFSOP, 4 Lead
Operating Temperature Range: -40°C to 100°C
Status: Common-used part with high popularity
Supply and Demand Status: Limited
Alternative Parts: FODM3022, FODM3023R4, FODM3022R1_NF098, and FODM3023R1_NL
