Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Applications Video
Switch Circuit SPDT
Number of Channels 7
Max On Resistance 9 Ohm
Single Supply Voltage (V+) 3 V to 3.6 V, 4.5 V to 5.5 V
-3db Bandwidth 1.3GHz
Features DDC CLK, DDC DAT, HSYNC, RGB, VSYNC
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 32-WQFN-EP (3x6)
Win Source Part Number 117927-TS3V712ELRTGR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TS3V712ELRTGR CAD Model

Description

Overview of Texas Instruments TS3V712ELRTGR

The Texas Instruments TS3V712ELRTGR is a high-performance, 4-channel video amplifier designed to cater to the demanding requirements of video and high-speed data transmission applications. This device is part of TI's extensive video amplifier portfolio, offering designers a blend of speed, low distortion, and high bandwidth to enhance the quality and integrity of video signals.

Key Features

  • High Bandwidth: The TS3V712ELRTGR boasts a high bandwidth of 400 MHz, which is essential for maintaining signal fidelity in high-resolution video applications.
  • Low Power Consumption: Engineered for efficiency, this video amplifier operates with low power consumption, making it suitable for portable and battery-powered devices.
  • 6-dB Gain: The device is configured with a fixed gain of 6 dB to enhance signal amplitude, improving the overall signal-to-noise ratio.
  • Single Supply Operation: It operates from a single 5V supply, simplifying the power supply design and ensuring easy integration into a wide range of systems.
  • Rail-to-Rail Output: The rail-to-rail output feature enables the amplifier to drive signals to the very edges of the power supply range, maximizing dynamic range.

Applications

The TS3V712ELRTGR is ideally suited for a variety of applications, including:

  • High-definition television (HDTV) receivers
  • Professional video editing and broadcasting equipment
  • Video-on-demand systems
  • Security and surveillance video systems
  • Automotive rearview camera and entertainment systems

Reliability and Packaging

Texas Instruments is known for its commitment to reliability, and the TS3V712ELRTGR is no exception. It is provided in a compact QFN package, which ensures a minimal footprint on the PCB while offering excellent thermal performance. The device is also characterized for operation from -40°C to 85°C, ensuring robust performance across a wide range of environmental conditions.

Conclusion

In summary, the Texas Instruments TS3V712ELRTGR video amplifier is a state-of-the-art component that provides designers with the performance and reliability needed for cutting-edge video and data transmission systems. Its combination of high bandwidth, low power, and ease of use makes it an excellent choice for a multitude of video applications.
