Product Overview: TS3USB30RSWR from Texas Instruments

The TS3USB30RSWR is a high-performance, low-power, single-lane USB 2.0 high-speed (480-Mbps) switch from Texas Instruments, designed to deliver efficient switching between two USB sources or destinations. This versatile switch is an ideal choice for a wide array of USB applications, including computing, docking stations, peripherals, and portable electronics.

Key Features

• USB 2.0 Compatibility: The TS3USB30RSWR is fully compatible with the USB 2.0 standard, offering high-speed data transfer capabilities essential for modern USB-connected devices.
• Low On-Capacitance (C_ON): The low on-capacitance of the switch ensures minimal signal degradation, which is critical for maintaining signal integrity at high-speed data rates.
• Low Power Consumption: With its low power consumption, the TS3USB30RSWR is suitable for battery-powered devices, helping to extend battery life and reduce overall power usage.
• Wide Operating Temperature Range: The device operates across a broad temperature range, making it suitable for various environments and applications.
• Space-Saving Package: The switch is available in a compact WQFN package, which is ideal for space-constrained applications.

Applications

The TS3USB30RSWR is designed to serve a diverse set of applications, including but not limited to:

• USB peripheral sharing
• USB port isolation and protection
• Signal multiplexing for USB interfaces
• Docking stations and port replicators
• Handheld and portable consumer electronics

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the TS3USB30RSWR is no exception. It is manufactured to meet high standards, ensuring stable performance and a long operational lifespan, which is particularly important for mission-critical or continuous-use applications.

In summary, the TS3USB30RSWR from Texas Instruments is a robust, efficient, and versatile USB 2.0 switch that offers seamless integration into various USB applications. Its combination of high-speed data transfer, low power consumption, and compact packaging makes it an excellent choice for designers looking to enhance their USB-enabled designs.
