The TPS62160DSGT from Texas Instruments is a highly efficient synchronous step-down converter, belonging to a family of devices that are designed to provide precise voltage regulation while maintaining a high power efficiency and a low quiescent current. This makes the TPS62160DSGT an ideal choice for power-sensitive applications.

Key Features

• Input Voltage Range: The device supports a wide input voltage range from 3V to 17V, making it suitable for a variety of power sources, including multi-cell batteries and regulated 12V rails.
• Adjustable Output Voltage: The output voltage is adjustable and can be set from 0.9V to 6V, providing flexibility for different design requirements.
• High Efficiency: With its synchronous step-down converter design, the TPS62160DSGT achieves up to 95% efficiency, which helps to minimize heat generation and improve battery life in portable applications.
• Low Quiescent Current: The device features a low quiescent current of typically 17μA, contributing to extended battery life when in standby mode.
• Power Save Mode: For additional power conservation at light loads, the TPS62160DSGT includes a Power Save Mode that reduces switching frequency to maintain high efficiency.
• Thermal and Overcurrent Protection: The built-in thermal shutdown and overcurrent protection mechanisms provide reliable operation and safeguard the device and downstream components from damage due to excessive heat or current.

Applications

The versatile TPS62160DSGT is suitable for a wide range of applications, including but not limited to:

• Portable and battery-powered equipment
• Point of Load conversions from 12V rails
• Embedded systems
• Power supplies for sensors, MCUs, and DSPs

Package and Availability

The TPS62160DSGT comes in a compact 8-pin WSON package with a small footprint, ideal for space-constrained applications. It is available for order and can be sourced directly through Texas Instruments or through authorized distributors globally.

For detailed technical specifications, application notes, and support resources, please refer to the official Texas Instruments website or contact their customer support team.
