Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Tube
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 2
Input Voltage MIN 4.5V
Voltage Input MAX 28V
Output Voltage 0.8V
Output Voltage MAX 25.2V
Output Current 3A
Frequency - Switching 630kHz
Synchronous Rectifier No
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting SMD
Package 14-TSSOP (0.173", 4.40mm Width) Exposed Pad
Manufacturer Package 14-HTSSOP
Win Source Part Number 1272626-TPS54386PWP
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TPS54386
Introduction Date June 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TPS54386PWP CAD Model

Description

The TPS54386PWP from Texas Instruments is a versatile and efficient dual-output, non-synchronous buck converter integrated circuit (IC) designed for a wide range of applications. This power management device is capable of providing two independent output voltages that range from 2.95V to 6V from a single input voltage between 4.5V and 28V, making it an ideal solution for systems that require multiple supply voltages.

With its integrated 3-A switches, the TPS54386PWP offers a compact power supply solution with a minimal external component count, which is perfect for space-constrained applications. Each channel is capable of delivering up to 3A of continuous current, which can be beneficial for powering FPGAs, DSPs, microcontrollers, and other digital ICs that require stable and efficient power supplies.

The TPS54386PWP features a fixed switching frequency that is adjustable from 280 kHz to 700 kHz, allowing designers to optimize the performance of their power supply for efficiency or component size. The device also includes a frequency synchronization input that enables the power supply to be synchronized to an external clock, thus reducing noise and potential interference in sensitive applications.

One of the key benefits of the TPS54386PWP is its thermal performance. The device is offered in a thermally enhanced 20-pin HTSSOP (PWP) package, which helps to dissipate heat more effectively and ensures reliable operation under varying load conditions. Additionally, the IC features a range of built-in protection features including under-voltage lockout, overcurrent protection, and thermal shutdown to safeguard the system against fault conditions.

For ease of use, the TPS54386PWP also includes an internal soft-start mechanism that limits inrush current during startup, thereby providing a smooth power-up sequence for sensitive electronic components. This feature, along with its high efficiency and flexibility, makes the TPS54386PWP a robust and versatile choice for a wide array of power supply designs.

Overall, the TPS54386PWP from Texas Instruments is a powerful, dual-channel buck converter that offers high efficiency, design flexibility, and reliability for designers looking to create compact and high-performance power supply systems.
