Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 8V
Maximum Input Voltage 36V
Nominal Output Voltage (Min/Fixed) 1.235V
Maximum Output Voltage 34V
Output Current 1A
Frequency - Switching 250kHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 018327-L6902D013TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian L6902D013TR CAD Model

Description

The L6902D013TR is a high-performance, adjustable step-down switching regulator manufactured by STMicroelectronics, a leader in the semiconductor industry. This efficient power management integrated circuit is designed to deliver a precise, regulated output voltage from a wider input voltage range. The device is ideal for a variety of applications, including consumer electronics, automotive systems, and industrial equipment.

Key Features

  • Adjustable Output Voltage: The L6902D013TR allows for an adjustable output voltage that can be set using external resistors. This flexibility makes it suitable for powering various devices requiring different voltage levels.
  • High Efficiency: With its advanced design, this regulator provides high efficiency, which helps in reducing power losses and improving overall system performance.
  • Wide Input Voltage Range: The device supports a broad input voltage range, enabling it to handle fluctuating input power and making it versatile for use in multiple environments.
  • Thermal Protection: The built-in thermal shutdown feature protects the device and the system from damage due to overheating, ensuring reliable operation under various conditions.
  • Low Dropout Operation: The L6902D013TR is capable of low dropout operation, which allows it to continue regulating the output voltage even when the input supply voltage is very close to the output voltage.

Applications

The L6902D013TR's robust design and adjustable output make it suitable for a wide range of applications. It can be used in portable devices where battery life is critical, in automotive applications where reliability and performance are paramount, and in industrial systems that require stable and efficient power supplies. Its versatility also extends to power conditioning for sensitive electronics, such as communication devices and microcontrollers.

Product Packaging

This product comes in a compact surface-mount package, specifically in a Tape & Reel (TR) format, which is suitable for automated assembly processes. The L6902D013TR's packaging ensures that it can be integrated into a variety of product designs with ease, while maintaining a small footprint on the PCB.
