Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Type Source Selector Switch
Transistor Polarity N-Channel
Internal Switch(s) Yes
Delay Time - ON 1ms
Delay Time - OFF 5ms
Current - Output (Maximum) 1.25A
Supply Current 55μA
Supply Voltage (V) 2.8V ~ 5.5V
Applications Handheld/Mobile Devices
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-TSSOP
Supplier Device Package 8-TSSOP
Family Part Number TPS2115A
Manufacturer Pack Quantity 150
MSL Level 1 (Unlimited)
Win Source Part Number 1272178-TPS2115APW
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS2115APW CAD Model

Description

Overview of Texas Instruments TPS2115APW

The TPS2115APW from Texas Instruments is a versatile power multiplexer that allows seamless transition between two power sources. Designed with the modern electronics in mind, it is an ideal solution for systems that require a reliable and automatic switch between different power supplies.

Key Features

  • Automatic Switching: The TPS2115APW can automatically switch between two power sources, making it perfect for applications that need a backup power source or for managing power from different inputs.
  • Wide Voltage Range: With an input voltage range of 2.8V to 5.5V, this power multiplexer is compatible with a variety of low-voltage applications, from battery-powered devices to USB-powered gadgets.
  • Low On-Resistance: The low on-resistance of the internal FET switch ensures minimal voltage drop and power loss, thereby maximizing efficiency.
  • Current Limiting: Built-in current limiting protects the device and the power sources from over-current conditions, enhancing system reliability.
  • Cross-Conduction Blocking: It prevents cross-conduction when switching between sources, which could otherwise lead to potential damage.

Applications

The TPS2115APW is suitable for a wide range of applications. It is commonly used in:

  • Portable Devices: Smartphones, tablets, and other handheld gadgets benefit from its ability to switch between battery and external power without interruption.
  • Redundant Power Supplies: Critical systems in servers and networking equipment that require uninterrupted power supplies.
  • Power Supply Orchestration: Systems that need to manage power from multiple sources, such as solar panels and batteries in energy harvesting applications.

Technical Specifications

Some of the technical specifications of the TPS2115APW include:

  • Package: 8-pin PW (TSSOP)
  • Operating Temperature Range: -40°C to 85°C
  • Switch On-Resistance: Typically 105 mΩ at 5V

With its robust feature set and reliable performance, the TPS2115APW from Texas Instruments stands out as a smart choice for designers looking to enhance power management in their electronic systems.
