TMP102AQDRLRQ1

Part No TMP102AQDRLRQ1
Manufacturer Texas Instruments
Catalog Temperature Sensors - Analog and Digital Output
Description SENSOR DIGITAL -40C-125C 6SOT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors
Estimated Pruduction Lead Time 34 Weeks
Features Temperature Sensor Digital, Local -40°C ~ 125°C 11 b
Manufacturer Texas Instruments
Series Automotive, AEC-Q100
Package Reel - TR
Operating Temperature Range -55°C ~ 150°C
Mounting Surface Mount
Package SOT-563, SOT-666
Family Name TMP102
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number TMP102AQDRLRQ1-ND, 296-40676-1, 296-40676-2, -296-40676-1-ND, 296-40676-6
Quantity per package 4000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 900417-TMP102AQDRLRQ1
Ultra Librarian 3D Model Ultra Librarian TMP102AQDRLRQ1 CAD Model

Description

The TMP102AQDRLRQ1 is a high-precision digital temperature sensor from Texas Instruments, designed for the automotive industry with a robust feature set that ensures performance in the most demanding applications. This tiny, low-power device offers excellent temperature accuracy and is ideal for a wide range of temperature sensing applications within a vehicle.

Key Features

  • High Accuracy: The TMP102AQDRLRQ1 boasts a ±0.5°C (max) accuracy from -40°C to 125°C, making it suitable for critical temperature monitoring.
  • Low Power Consumption: With a typical supply current of 10µA in active mode and 1µA in shutdown mode, this sensor is an energy-efficient choice for battery-powered systems.
  • Digital Output: The sensor features a two-wire, SMBus, and I2C interface for easy integration with microcontrollers and other digital systems.
  • Small Size: Housed in a tiny SOT-563 package, the TMP102AQDRLRQ1 is perfect for space-constrained applications.
  • Wide Temperature Range: It operates over a temperature range of -40°C to +125°C, suitable for various environments and climates.
  • Quality and Reliability: As a Q1 automotive-qualified product, it meets the stringent quality and reliability standards required for automotive applications.

Applications

The TMP102AQDRLRQ1 is versatile and can be used in a variety of automotive applications, including climate control, engine cooling systems, battery management, and temperature monitoring for infotainment systems and LED lighting. Its small footprint and precision also make it suitable for industrial and consumer applications where accurate temperature data is crucial.

Conclusion

In summary, the TMP102AQDRLRQ1 from Texas Instruments is a state-of-the-art digital temperature sensor that combines high accuracy, low power consumption, and a small form factor. Its robust design and wide temperature range make it an ideal choice for automotive applications that require reliable and precise temperature monitoring.
