Products specifications

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Reference
Mfr Texas Instruments
Package Tape & Reel
Product Status Active
Reference Type Shunt
Output Type Adjustable
Voltage - Output (Min/Fixed) 2.495V
Voltage - Output (Max) 36 V
Current - Output 100 mA
Tolerance ±1%
Current - Cathode 700 µA
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case TO-243AA
Supplier Device Package SOT-89-3
Base Product Number TL432
Standard Package 1,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 899790-TL432AQPKG3
Ultra Librarian 3D Model Ultra Librarian TL432AQPKG3 CAD Model

Description

Product Overview: TL432AQPKG3 from Texas Instruments

The TL432AQPKG3 is a precision programmable reference from Texas Instruments, designed to offer a reliable voltage reference solution for various applications. This versatile device is a three-terminal adjustable shunt regulator with specified thermal stability over applicable automotive, commercial, and military temperature ranges. The TL432AQPKG3 has the capability to operate with a wide current range from 1mA to 100mA, making it suitable for flexible design requirements.

With an output voltage range that can be set to any value between Vref (approximately 2.5V) and 36V with two external resistors, the TL432AQPKG3 provides excellent design flexibility. This feature allows designers to tailor the voltage reference to meet the specific needs of their circuit. Additionally, the device features a typical output impedance of 0.2 ohms, providing stable reverse breakdown voltage accuracy over a wide range of operating temperatures and currents.

The TL432AQPKG3 is characterized for operation from -40°C to 125°C, ensuring its reliability and performance in harsh environments. This makes it an ideal choice for automotive applications, power supplies, and other electronics that require a high level of thermal stability. The device comes in a variety of packages, including the small outline transistor (SOT-23) which is popular for space-constrained applications.

Key features of the TL432AQPKG3 include a low output noise voltage, fast turn-on response, and a trimmable reference voltage. This allows for precise control and adjustment, which is critical in maintaining the accuracy of the voltage reference in the final application. The TL432AQPKG3 is also an excellent choice for use in portable electronics due to its low power consumption and small size.

Overall, the TL432AQPKG3 from Texas Instruments is a robust and flexible solution for designers who require a high-performance, adjustable voltage reference. Its wide operating range, precision, and stability make it an essential component for a broad spectrum of applications, from power management to precision instrumentation.
