Product Overview: SN74LVTH162373DGGR

The SN74LVTH162373DGGR is a high-performance integrated circuit from Texas Instruments, designed to meet the demanding requirements of modern digital systems. This 16-bit transparent D-type latch is part of the LVTH family, which stands for Low-Voltage BiCMOS Technology with TTL-Compatible Inputs. This device is particularly suitable for applications that require high-speed data storage and transfer, with the added benefit of a 3-state output for bus-oriented systems.

Key Features

• Low-Voltage Operation: Operates at a nominal voltage of 2.5V to 3.3V, which allows for lower power consumption and makes it ideal for battery-operated and power-sensitive applications.
• High-Speed Performance: With a typical shift frequency of 250 MHz, it is capable of handling high-speed data with ease, making it suitable for telecommunications, computing, and high-speed data acquisition systems.
• 16-Bit Transparent Latch: Features 16 D-type transparent latches with 3-state outputs, providing ample data storage capability while allowing for bus connectivity.
• 3-State Outputs: The 3-state outputs can be placed in a high-impedance state, effectively disconnecting the output from the bus, which is crucial for bus-oriented systems to avoid conflicts.
• Flow-Through Architecture: Optimizes the PCB layout by facilitating easier routing of data lines.
• Edge-Rate Control Circuitry: Minimizes output skew and reduces signal transition-related noise, ensuring data integrity during high-speed operation.

Applications

The SN74LVTH162373DGGR is versatile and can be used in a variety of applications, including:

• Server and Networking Equipment
• Telecommunications Infrastructure
• High-speed Data Acquisition Systems
• Computers and Computer Peripherals
• Industrial Control Systems

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability. The SN74LVTH162373DGGR is no exception, providing the performance and durability that professionals expect from a leading semiconductor manufacturer. The device is available in a 48-pin TSSOP (DGGR) package, ensuring compatibility with standard surface-mount assembly processes and easy integration into a wide range of products.

For detailed specifications and application notes, designers and engineers are encouraged to consult the official Texas Instruments datasheets and product guides.
