SN74LS10DR Texas Instruments SN74LS10DR Real Image1 SN74LS10DR Real Image2
Same model may have multiple batches, images only for reference.
SN74LS10DR Texas Instruments SN74LS10DR Real Image1 SN74LS10DR Real Image2
SN74LS10DR Texas Instruments SN74LS10DR Real Image1 SN74LS10DR Real Image2
Same model may have multiple batches, images only for reference.

SN74LS10DR

Part No SN74LS10DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 3CH 3-INP 14-SOIC
Datasheet
SN74LS10DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 3
Number of Inputs 3
Supply Voltage - Operating 4.75 V to 5.25 V
Current - Quiescent (Max) 6mA
Current - Output High, Low 400μA, 8mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 15ns @ 5V, 15pF
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 084112-SN74LS10DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SN74LS10DR CAD Model

Description

The SN74LS10DR is a high-performance integrated circuit (IC) produced by Texas Instruments, a renowned American technology company that designs and manufactures semiconductors and various integrated circuits.

  • Description: triple three-input positive NAND gate device
  • VCC Operating Voltage Range: 4.75 to 5.25 volts
  • Typical Propagation Delay Time: 10ns
  • Circuitry: Schottky-clamped circuitry
  • Package: compact SOIC (Small Outline Integrated Circuit) package
  • Compliance: RoHS compliant
